Lenovo ThinkSmart Core and Controller Kit in Black - 11LR000BUS

Specifications:

Performance

• Processor: Intel Core i5-1145G7E (4C / 8T; 1.5 / 4.1GHz; 8MB)
• Graphics: Integrated Intel Iris Xe Graphics
• Chipset: Intel SoC Platform
• Memory: 1x 16GB Soldered DDR4-3200
• Memory Slots: Memory soldered to systemboard; no slots; dual-channel
• Max Memory: 16GB soldered memory; not upgradable
• Storage: 256GB SSD M.2 2280 PCIe 3.0x4 NVMe
• Storage Support: One drive; up to 256GB SSD
• Power Supply: 90W 89% Adapter
• Case Color: Black (ThinkSmart Core + ThinkSmart Controller)
• Mounting: Integrated VESA Mount
• Component Options:
• ThinkSmart Core + ThinkSmart Controller
• 1x ThinkSmart Core
• 1x ThinkSmart Controller
• Controller: ThinkSmart Controller; 10.1" Display; 10-point Multi-touch
• Camera Component: None
• Microphone Component: None
• Audio Bar: None

Connectivity

• Ethernet: Integrated 100/1000M
• WLAN + Bluetooth: Intel Wi-Fi 6 AX201; 802.11ax 2x2 + BT5.0; vPro
• Rear Ports:
• 1x Thunderbolt 4
• 1x USB-C 3.2 Gen 1
• 1x USB-C 3.2 Gen 2
• 1x USB 3.2 Gen 1
• 2x USB 3.2 Gen 2
• 1x HDMI-in
• 2x HDMI-out 1.4
• 1x Ethernet (RJ-45)
• 1x power connector

Security & Privacy

• Security Chip: Discrete TPM 2.0; TCG certified
• Physical Locks: Kensington Security Slot

Manageability

• System Management: Intel vPro

Service

• Included Upgrade: First Year Maintenance; 3Y Premier Support Upgrade from 3Y Onsite

Software

• Operating System: Windows 11 IoT Enterprise for Collaboration GAC 64; English
• Bundled Software: Microsoft Teams Rooms

Dimensions

• Dimensions (W x D x H):
• ThinkSmart Cam: 105 x 60.5 x 36 mm (4.1 x 2.4 x 1.4 in.)
• ThinkSmart Core: 226 x 200 x 37.5 mm (8.9 x 7.9 x 1.5 in.)
• ThinkSmart controller: 265.5 x 13 x 168.1 mm (10.5 x 0.5 x 6.6 in.)
• ThinkSmart controller with stand: 265.5 x 83.3 x 168.1 mm (10.5 x 3.3 x 6.6 in.)
• ThinkSmart Bar: 800 x 90 x 55 mm (31.5 x 3.5 x 2.2 in.)
• Satellite Microphone:
• Diameter: 100 mm (3.9 in.)
• Height: 20 mm (0.8 in.)
• Weight:
• ThinkSmart Core: 1.1 kg (2.4 lbs)
• Satellite Microphone: 220 g (0.5 lbs)
• ThinkSmart Cam: 220 g (0.5 lbs)
• ThinkSmart Bar: 1.9 kg (4.2 lbs)
• ThinkSmart controller: 753.8 g (1.7 lbs)

Warranty

• Base Warranty: First Year Maintenance; 3-year Premier Support Upgrade from 3-year Onsite
