Panasonic 70-200mm F4 O.I.S. LUMIX S PRO Lens For L-Mount Cameras+7 Yr Warranty



The Panasonic LUMIX S PRO S-R70200 70-200mm F4 Telephoto lens with O.I.S. provides high-resolution, high-contrast images across the entire zoom range making it perfect for portraits to sports. The Panasonic LUMIX 5-Axis Dual I.S. (Image Stabilizer) 2 [*1] system can be used with the LUMIX S PRO as a lens for a full-frame mirrorless camera system. LEICA Certified to Leica standards, this Telephoto Lens is an interchangeable Full Frame L-Mount.

The O.I.S. (Optical Image Stabilizer) in the lens effectively compensates for hand-shake movement, making it easy to shoot without a tripod. This Panasonic LUMIX S PRO lens offers high-precision Auto Focus to capture every photo opportunity. The focus clutch mechanism enables both instant AF/MF switching and accurate manual focusing. Focus breathing is suppressed making it an excellent choice for video recording.

Camera performance, lightweight construction, and Dust/Splash*/Freeze-Resistant Design are some of the features you’ll enjoy while shooting with the Panasonic LUMIX S Series lens.

Product Highlights:

LUMIX S PRO CAMERA LENS – 70-200mm telephoto zoom F4 L-mount lens, LEICA certified for LUMIX S Series Full-Frame digital mirrorless cameras

O.I.S. STABILIZATION – Complies with LUMIX camera Body I.S.; 5-Axis Dual I.S. 2 makes it possible to use 6-stop slower shutter speed

LENS ELEMENTS – 23 lenses in 17 groups; an aspherical lens and 3 ED (Extra-low Dispersion) lenses effectively suppress both axial chromatic aberration and chromatic aberration of magnification

LENS FOCUSING – A double focus system combines a linear motor and stepping motor to achieve sensor drive at a maximum speed of 480 fps for fast, high-precision autofocus

RUGGED LENS DESIGN – Dust/splash/freeze-resistant design withstands use under harsh conditions for high mobility

Product Features:

Image Stabilization for Blur-free Image

Optical image stabilizer (O.I.S.) in the lens effectively compensates for hand-shake movement, making it easy to shoot even without a tripod or in low-lit situations.

Rugged Design for Intrepid Photography

This lens is dust- and splash-resistant and designed for use at temperatures as low as 14 °F. It is tough enough to withstand even heavy field use.

Video Support for Perfect Recording

In addition to silent design, the lens offers both stunning autofocus and smooth aperture changes. This top-level performance allows you to record beautiful, ultra-sharp 4K video.

Welcome to new possibilities: the L-Mount

Leica Camera, Panasonic and Sigma now offer a solution that allows ‘mix and match' of any of the three manufacturers’ APS-C and full-frame cameras with any lens from each other’s product portfolios.

S-R70200: Construction

The optimized configuration has 23 lenses in 17 groups with an aspherical and 3ED (extra-low Dispersion) lenses that effectively suppress both axial and magnification chromatic aberrations.

S-R70200: MTF Chart

For lenses that are capable of compensating distortion, the horizontal axis of the MTF shows the distance from the center of the corrected image.

Product Specifications:

Mount - Leica Camera AG L-Mount

Focal Length - f=70mm to 200mm

Lens Construction - 23 elements in 17 groups (1 aspherical lens, 1 UED lens, 3 ED lenses, 1 UHR lens)

Aperture Type - 9 diaphragm blades/ Circular aperture diaphragm

Maximum Aperture - F4.0

Minimum Aperture Value - F22

Angle of View - 34 Degrees (Wide) to 12 Degrees (Tele)

Recording Range - 0.92mm (3.02 feet) to (from the focus distance reference line)

Maximum Image Magnification - 0.25x

Image Stabilizer - Yes

Filter Diameter - 77mm

Maximum Diameter - 84.4mm (3.3")

Overall Length - Approx. 179mm (7.0") (from the tip of the lens to the base side of the lens mount)

Mass (Weight) - Approx. 985g (2.17 lb) (excluding the external tripod mount)

Dust and Splash Resistant - Yes

Recommended Operating Temperature - -10 Degrees C to 40 Degrees C (14 Degrees F to 104 Degrees F)

Permissible Relative Humidity - 10 Percent RH to 80 Percent RH
